I/O Connector
Return
Technical Parameter
Parameter Item | Specification |
Product Type | Type-C Female Connector |
Pin | 16P |
Mounting Type | Vertical SMT |
Structure Type | Short Full Plastic Custom Version |
Mated Height | 6.43mm |
Board Height (Raised) | 5.91mm |
Overall Length | 8.0mm |
Housing Pin Width | 0.65mm |
Return
Technical Parameter
Parameter Item | Specification |
Product Type | Type-C Female Connector |
Pin | 16P |
Mounting Type | Vertical SMT |
Structure Type | Short Full Plastic Custom Version |
Mated Height | 6.43mm |
Return
Technical Parameter
Parameter Item | Specification |
Product Type | Type-C Female Connector |
Pin | 16P |
Mounting Type | Vertical SMT |
Structure Type | Short Full Plastic Custom Version |
Mated Height | 6.43mm |
Return
Technical Parameter
Product Description | USB 3.1 Type‑A Female 90° Forward Sink‑in DIP Receptacle, Flange / No Flange |
Type | Type‑A Female |
Style | 90° Forward Sink‑in DIP |
Mounting | DIP |
CH (mm) | 0.10 & 0.64 |
DIM L×W×H(mm) | 13.9×5.72×2.96 & 3.5 |
Flange | Yes / No |
Solder Pin Length(mm) | 1.8 & 1.6 |
Bend Pin W(mm) | 1.8 & 1.5 |
Return
Technical Parameter
Product Description | USB 3.1 Type‑A Female 90° DIP On‑Board Receptacle |
Type | Type‑A Female |
Style | 90° DIP On‑Board |
Mounting | DIP |
CH(mm) | 4.13 |
DIM L×W×H(mm) | 16.5×7.42×6.99 |
Flange | Yes / No |
Solder Pin Length(mm) | 2.17 |
Bend Pin W(mm) | 15.6 |
Straight Pin Length(mm) | 2.2 |
Return
Technical Parameter
Product Description | USB 3.1 Type‑A Female 90° Reverse Sink‑in DIP Receptacle, No Flange |
Type | Type‑A Female |
Style | 90° Reverse Sink‑in DIP |
Mounting | DIP |
Sink-in H | ‑0.3 mm |
DIM L×W×H | 15.60×5.72×2.56 mm |
Flange | No |
Solder Pin Length | 1.4 mm |
Straight Pin Length | 1.4mm |
Return
Technical Parameter
Product Description | USB 3.1 Type‑A Female 90° Reverse Sink‑in DIP Receptacle, No Flange |
Type | Type‑A Female |
Style | 90° Reverse Sink‑in DIP |
Mounting | DIP |
Sink-in H | ‑2.54 & ‑2.40 mm |
DIM L×W×H | 16.37×5.4×2.3 & 2.44 mm |
Flange | No |
Solder Pin Length | 1.45 & 1.26 mm |
Straight Pin Length | 2.1 & 0.85 mm |
Return
Technical Parameter
Product Description | USB 3.0 Type‑B Female 90° DIP Receptacle |
Type | Type‑B Female |
Style | 90° DIP |
Mounting | DIP |
H | 12.4/12.6/12.9 mm |
DIM L×W | 18.30×12.51 mm |
Solder Pin Length | 2.1 mm |
Bend Pin W | 2.1 mm |
Return
Technical Parameter
Product Description | USB 3.0 Type‑B Female 90° DIP Receptacle |
Type | Type‑B Female |
Style | 90° DIP |
Mounting | DIP |
H | 12.4/12.6/12.9 mm |
DIM L×W | 18.30×12.21 mm |
Solder Pin Length | 2.2/2.38/2.5/2.70 mm |
Bend Pin W | 14.4 mm |
Return
Technical Parameter
Product Description | USB 2.0 Type‑A Female 90° DIP Reverse Sink‑in Short‑Body Receptacle, Flat Mouth |
Type | Type‑A Female |
Style | 90° DIP Reverse Sink‑in |
Mount Type | Flat Mouth |
Layer | Short-Body |
Sink-in H | -1.34 |
CH (Case Height) | 7.2 mm |
DIM (L×W×H) | 12.5×5.4×1.36 mm |
Flange | No |
Solder Pin Length | 1.35 mm |
Straight Pin Length | 1.35 mm |
Return
Technical Parameter
Product Description | USB 2.0 Type‑A Female 90° Side‑Entry DIP Receptacle, Long‑Body |
Type | Type‑A Female |
Style | 90° Side-Entry |
Mounting | DIP |
Layer | Long-Body |
CH (Case Height) | 7.2 mm |
DIM (L×W×H) | 19.40×13.1×13.75 |
Flange | Yes /No |
Solder Pin Length | 3.0 mm |
Bend Pin W | 7.0 mm |
Return
Technical Parameter
Product Description | USB 2.0 Type‑A Female 90° Dual‑Layer DIP Receptacle, With Stake‑in Lugs & Flange |
Type | Type‑A Female |
Style | 90° |
Mounting | DIP |
Layer | Dual‑Layer |
CH (Case Height) | 3.55 mm |
DIM (L×W×H) | 16.7×14.3×10.5 mm |
Flange | Yes (With Flange) |
PIN Length | 2.5 mm |
Stake‑in Lugs W | 2.5 mm |
